Cranberry physics

Cranberry physics intro

Attention Work in progress

I want physics, ability to query the scene for purposes like audio occlusion and of course for game play queries. I took a look at Bullet and Jolt, decided to go with Jolt due to following reasons.

• Open source MIT
• Multithreaded
• Probably good enough for most of the use case I will ever have
• JobSystem integration is supported and simple
• Customizable filters are good enough to support my use cases

Jolt physics engine notes

Integrate Jolt JobSystem

Jolt’s JobSystem is just an interface with few simple rules.

• Jobs are created and destroyed with this interface.
• Each job can be included in only one barrier this makes things so much simpler.
• JobSystem, Barrier, Jobs has to be overridden to support custom behavior.
• Jobs are reference counted and lifetime is managed by that.

The goal here is to integrate the Jolt job system interface to use engine’s global JobSystem. Since our JobSystem supports single threaded mode we need two of job system and other interface implementations. One for full multithreaded mode with at least 1 worker thread and another for single threaded mode where each job on enqueue gets executed immediately.

Before we can start looking at JobSystem itself we have to provide a custom implementation for Barriers.

Barriers

Barriers are just a collection of Jobs that can be waited on for completion. It has two function AddJob and OnJobFinished exposed as interface.

In our case

• AddJob just adds job handle or reference to a thread safe linked list. Adding a Job to barrier must add a reference to reference counter. Destroying barrier will wait for all tasks to complete.
• OnJobFinished does not have to do anything as Job enqueueing happens at either Job construction if no dependencies or when number of dependencies drops to 0.

Barrier can use same implementation for both Single and Multithreaded mode. Exception is when waiting.

Wait function flow

• In single threaded mode, Go through each job in the list
  • Execute the ones that can be executed. Executing is not needed as enqueueing must execute the whole tree however it is okay to execute here as well.
  • Remove the jobs that are done.
  • Do this until there is until there is no more Jobs.
  • Assert the list is empty to make sure there is no missing dependencies.
  • Clear the rest of the jobs.
• In multithreaded mode the steps are bit different. We can also assume that barrier never gets waited from a worker thread as Jolt never uses barrier as a way to manage dependencies between jobs. This assumption or fact makes dead lock related issues to not happen when worker threads uses different queues. If inter job dependencies are handled using Barrier then we have problem if barrier wait is queued before queueing the dependent job in the same queue. In this case barrier waits for job queued in thread’s same queue which has no chance to dequeue, there by creating dead lock.
  • CAS get the linked list head with nullptr. This is to prevent further adding of jobs to same linked list.
  • Count the number of jobs that are already enqueued or waiting for dependencies using some custom data structure.
  • Collect those enqueued jobs in another container to be used with copat::awaitAllTasks.
  • Now wait for jobs using copat::waitOnAwaitable
  • Remove the done jobs from the linked list.
  • Repeat the steps 2 to 5 until there is no more done jobs cleared from linked list.
  • Assert the list is empty to make sure there is no missing dependencies.
  • Clear the rest of the jobs.

Job

Each Job must hold some custom data to track coroutine and the job enqueued into the CoPaT JobSystem. Even though the Jolt’s Job has a done status check it cannot alone be relied of if going to destroy a coroutine. As coroutine might still be in progress even after the Jolt job is done.

Instead of overriding the Job I decided to contain the Job inside a JobPacket in cranberry engine.

namespace cbe::physics
{
struct JobPacket
{
    JPH::Job joltJob;
    /* Inline chain to next entry in Barrier's Job list, Do not need atomic here as head in Barrier will be atomic */
    JobPacket *barrierNext;

    struct MultiThreadData
    {
        CopatTask task;
        /* For tracking if job is already enqueued, This is necessary since Barrier works outside the coroutine framework of CoPaT JobSystem */
        std::atomic_bool bEnqueued;
    };
    struct SingleThreadData
    {
        JobPacket *next;
    };
    /* MultiThreadData task data is not needed for single threading */
    union
    {
        MultiThreadData mt;
        SingleThreadData st;
    } taskData;
};
}

This way we can easily interop between JobPacket and Job.

JobSystem

There will be two implementation of JobSystem and one selected based on the multithreading constraints in CoPaT’s JobSystem.

In single threaded mode

• GetMaxConcurrency always returns 1
• CreateJob will create jobs from a preallocated pool until it gets exhausted.
• FreeJob returns the Job to preallocated pool or free the dynamically allocated memory.
• CreateBarrier will create from a preallocated pool until it gets exhausted.
• DestroyBarrier returns the barrier to preallocated pool or free the dynamically allocated memory.
• WaitForJobs will call the single threaded variant of wait in Barrier implementation.
• QueueJob and QueueJobs immediately executes based on reentrant condition. Enqueueing while reentering will add the Job to JobPacket::taskData.st.next in JobSystem’s queue list.

In multithreaded mode

• GetMaxConcurrency returns number of worker threads in copat::JobSystem.
• CreateJob will reuse already allocated job from a thread safe ring buffer pool. If no free jobs exists new job gets allocated and used.
• FreeJob returns the Job to ring buffer. If ring buffer is full frees the allocation.
• CreateBarrier Barriers are sparsely created so now it will be pool allocated. New barrier gets allocated from this thread unsafe pool allocator inside a lock.
• DestroyBarrier returns the barrier to the thread unsafe pool allocator inside lock.
• WaitForJobs will call the multi threaded variant of wait in Barrier implementation.
• QueueJob and QueueJobs Queues the Job for execution wrapped inside a coroutine. Fills the JobPacket::taskData.mt with task details.

Filter interfaces

The physics engine’s collision or queries system can be controlled to provide customized behavior required for engine using several filter or table interfaces. This is where the collision profiles of engine can be integrated.

Each of the collision or query starts from the BroadPhaseQuery then to NarrowPhaseQuery using body and shape. Each body has an ObjectLayer associated with it which is very important for filtering efficiently. In order to filter at Broad Phase the BroadPhaseLayer will be used. Each ObjectLayer must be associated with a BroadPhaseLayer and keeping number of broad phase layer as low as possible is important. Each broad phase layer has its own unique quad tree of AABBs where all the Bodies with mapped ObjectLayer gets added to.

BroadPhaseLayerInterface and ObjectVsBroadPhaseLayerFilter

This mapping of ObjectLayer to BroadPhaseLayer is provided by BroadPhaseLayerInterface. For now I have decided to have only three BroadPhaseLayers

1. Moveable - For all ObjectLayer that can be moved and cannot be made moveable later. Like static level objects that has no interaction possible other than block collision and world queries.
2. NonMoveable - For all ObjectLayer that can be moved even if created as static body and later moved using SetPosition.
3. Triggers - For all ObjectLayer that can be used as triggers or sensors.

The ObjectVsBroadPhaseLayerFilter interface is what is used to determine if an ObjectLayer can collide with a BroadPhaseLayer. The ObjectLayer comes from body being tested. The BroadPhaseLayer comes from the BroadPhase tree that is being tested in.

ObjectLayerPairFilter

Once BroadPhase filter is successful for each Body’s AABB in tree ObjectLayerPairFilter is invoke to decide whether to consider the Object layer each body belongs to. This check is done once for all the continuous bodies with same ObjectLayer, keep this in mind when deciding on what data to encode into ObjectLayer.

GroupFilter

GroupFilter is described to be used to filter simulation collisions at the global common level. The groups and subgroups can be assigned to each body to control the collisions. This GroupFilter is a way to simplify for an instance sub body collisions without expensive logics.

Some example use case will be

• Disable collisions between each adjacent elements in chain to keep the stability of the chain.
• Disable inter body smi collision between small moving parts in vehicles.

Right now I do not need GroupFilters for my use case but as soon as I have one I will update here on what and how to approach the case.

BodyFilter

This filter is used for queries and must be passed in with queries. So depending upon what is requested in a query we can issue different filter to support wider use case.

However the most important part I have in my mind right now is if we use a collider for both querying and simulation then we need to do additional look ups here to eliminate sim results. The way we do this checks and elimination depends on how we encode the ObjectLayer date into body and body user data.

ShapeFilter

This filter is used for queries and must be passed in with queries. So depending upon what is requested in a query we can issue different filter to support wider use case. However right now I do not see a point to have this implemented. As shapes alone might not be enough to check advanced filtering.

One use case I can think of is filter out complex shapes like mesh shape to reduce query complexity.

SimShapeFilter

SimShapeFilter is used for sim to filter out shapes for each body here we can filter bodies based on data from userdata.

Example use cases

• Simple LOD between mesh shape and simple shape.
• Filter out ObjectLayer mask if the body is used for querying too.

ContactListener

ContactListener is event callback to listen to and reject specific contact points. I do not have any use for this now.

Summary

Here is a short diagram of what I envision the filter interface will do in my engine now.

--- title: Flow --- flowchart LR subgraph BroadPhase subgraph olf_block["Object layer filter"] direction BT olf["Object layer filter"] olf_cmt@{ shape: braces, label: "In my engine this will be used to filter both query and sim filter mask encoded in **ObjectLayer**" } olf_cmt -.- olf end bpf["Broad phase layer filter"] bpf -- "`Select broad phase tree`" --> olf_block end subgraph cqf["Collision Query Flow"] direction LR subgraph bf_block["Body Filter"] direction BT bf["Body filter"] bf_cmt@{ shape: braces, label: "This filters out sim only filter mask from positive results of previous stage" } bf_cmt -.- bf end subgraph sf_block["Shape Filter"] direction BT sf["Shape filter"] sf_cmt@{ shape: braces, label: "This can be used for additional filters like whether to enable complex shapes like triangle mesh" } sf_cmt -.- sf end subgraph cc_block["Collision Collector"] direction BT cc["Collision Collector (AddHit)"] cc_cmt@{ shape: braces, label: "Custom collector if required can be implemented here." } cc_cmt -.- cc end olf_block -- "`Check AABB of bodies`" --> bf_block bf_block -- "`Iterate shape pairs or shapes`" --> sf_block sf_block -- "`Detect collisions between selected shapes or shape pairs`" --> cc_block end subgraph scd["Sim collision detection"] direction LR subgraph gf_block["Group Filter"] direction BT gf["Group Filter"] gf_cmt@{ shape: braces, label: "This can be used to filter collisions using group and subgroup IDs. Example to skip collisions in a chain of bodies to immediate next body for stability" } gf_cmt -.- gf end subgraph ssf_block["Sim Shape Filter"] direction BT ssf["Sim Shape filter"] ssf_cmt@{ shape: braces, label: "This can be used for additional filters like whether to enable complex shapes like triangle mesh, select LOD and most importantly filter out query only filter mask from positive results of previous stage" } ssf_cmt -.- ssf end subgraph cl_block["Contact Listener"] direction BT cl["Contact Listener"] cl_cmt@{ shape: braces, label: "Callback to listen to and reject specific contact point." } cl_cmt -.- cl end cp["Contact Points"] olf_block -- "`Check AABB of bodies`" --> gf_block gf_block -- "`Iterate shape pairs`" --> ssf_block ssf_block -- "`Detect collisions between shape pairs`" --> cl_block cl_block -- "`If not rejected`" --> cp end

Engine physics

For optimizing the collision detection as mush as possible I have decided to make each physics body to have separate mask of ObjectLayers. However for coarse Object layer filter these two will be encoded into the ObjectLayer of each body. Since each mask must be tested against another body’s Object layer itself we need to store both Object layer and body’s Object layer response. For this to work we need following conditions

• Change Jolt to use 32bit for ObjectLayer, this can be done using -DOBJECT_LAYER_BITS=32 cmake config
• Limit maximum number of Engine Object Layers to 26(0-25). This is to use the higher 26 bits of ObjectLayer as body response mask for both simulation and query combined.
• Use one bit for determining whether the mask has simulation response in it. Why simulation instead of query? This can be used to quickly reject simulation request if the there the body is never used for simulation. Where as for query if needs additional checks if sim is enabled to be sure if body needs to respond.
• Use 5bits for storing the body’s Object layer itself
• ObjectLayer filter will filter layers coarsely
• BodyFilter or SimShapeFilter filters the based on body’s sim or query response mask based on the filter used.

namespace cbe::physics
{
// same as sizeof(JPH::ObjectLayer) == 32bit
struct ObjectLayer
{
    uint32 bodyLayer : 5;
    uint32 isSimMask : 1;
    uint32 responseMask : 26;
};
}

These are the only special and most important case when it comes to filtering need to be handled by physics engine. Rest of the settings can be created 1:1 with Jolt to keep the interface simple.
